SCHNEIDER 140CPU65150 CPU modular

Brand: Schneider

Model: SCHNEIDER 140CPU65150 CPU modular

Origin: Switzerland

Warranty: 365 days

Quality: new/second-hand

Delivery method: express delivery

Telephone :+86 18020721390

WeChat:+86 18020721390Email:sakyzeng@foxmail.com

product details








SCHNEIDER 140CPU65160Number

The 140CPU65150 is a Unity processor in Schneider Electric’s Modicon Quantum series. It is a newer model in the series of processor modules. It combines the standard functions of the PLC and the diagnostic possibilities of a web server. It communicates using an RJ-45 connection. The module is in a double-width standard Quantum housing which requires two sequential slots in a Quantum rack. It has a clock frequency of 166 Mhz and has two local racks. It has 63 distributed I/O stations, 1 rack, and 3 distributed networks. It has 8000 discrete inputs and outputs of discrete in a distributed network, and 31744 discrete inputs and inputs in a remote system. As far as application-specific I/O, it can be used for time stamping, as a counter, for high-speed interrupt inputs, and as a serial link.


To use the 140CPU65150’s web server functions, software must be used to configure its services. The 140CPU65150 has a data rate of 10/100 Mbps. For a medium, a user should use a shielded twisted pair cable. The module has a number of services, including standard web service, Modbus TCP messaging, I/O scanning services, global data, FDR client, SNMP management, and SMTP services (email). It is compatible only with the Unity Pro software.


local rack(s)Number of distributed I/O station 63 station(s) - 1 rack(s) - 3 distributed network(s)Number of remote I/O station 31 - 2 remote rack(s)Discrete I/O number 8000 inputs, 8000 outputs - distributed - per network31744 inputs, 31744 outputs - remoteUnlimited (26 slots max) - localAnalogue I/O number Unlimited (26 slots max) - local500 inputs, 500 outputs - distributed - per network1984 inputs,1984 outputs - remoteApplication specific I/O Accurate time stampingCounterHigh-speed interrupt inputsSerial linkNumber of optional modules 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)Maximum number of connections Unlimited (AS-Interface) - local6 (Profibus DP) - local6 (Modbus Plus) - local6 (Ethernet TCP/IP) - local4 (AS-Interface) - remote2 (AS-Interface) - distributed1 (USB)1 (Modbus) - RS232/485 Modbus/ASCIIIntegrated connection type 1 Ethernet TCP/IP1 Modbus1 Modbus Plus1 USBChecks Process controlMemory description Expandable 8 MB - file storage with PCMCIA cardExpandable 7168 kB - program with PCMCIA cardInternal RAM 768 kBSwitch function Key switch memory port on/offApplication structure 4 auxiliary tasks32 timer interrupt tasks128 interrupt tasks128 I/O interrupt tasks1 periodic fast task1 cyclic/periodic master task2Execution time per instruction 0.48...0.56 µs floating points0.0525...0.075 µs Boolean0.045...0.06 µs on word0.045...0.06 µs on fixed-point arithmeticClock frequency 166 MHzNumber of slots 10Number of racks 2 - local rack(s)Number of distributed I/O station 63 station(s) - 1 rack(s) - 3 distributed network(s)Number of remote I/O station 31 - 2 remote rack(s)Discrete I/O number 8000 inputs, 8000 outputs - distributed - per network31744 inputs, 31744 outputs - remoteUnlimited (26 slots max) - localAnalogue I/O number Unlimited (26 slots max) - local500 inputs, 500 outputs - distributed - per network1984 inputs,1984 outputs - remoteApplication specific I/O Accurate time stampingCounterHigh-speed interrupt inputsSerial linkNumber of optional modules 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)Maximum number of connections Unlimited (AS-Interface) - local6 (Profibus DP) - local6 (Modbus Plus) - local6 (Ethernet TCP/IP) - local4 (AS-Interface) - remote2 (AS-Interface) - distributed1 (USB)1 (Modbus) - RS232/485 Modbus/ASCIIIntegrated connection type 1 Ethernet TCP/IP1 Modbus1 Modbus Plus1 USBChecks Process controlMemory description Expandable 8 MB - file storage with PCMCIA cardExpandable 7168 kB - program with PCMCIA cardInternal RAM 768 kBSwitch function Key switch memory port on/offApplication structure 4 auxiliary tasks32 timer interrupt tasks128 interrupt tasks128 I/O interrupt tasks1 periodic fast task1 cyclic/periodic master task2Execution time per instruction 0.48...0.56 µs floating points0.0525...0.075 µs Boolean0.045...0.06 µs on word0.045...0.06 µs on fixed-point arithmetic
