PPC907BE 3BHE02457R0101 | ABB Input/Output Interface Module

ABB PPC907BE 3BHE02457R0101 Input/Output Interface Module

· The EH series CPU can have up to 256 input points, numbered octal and ranging from X0 to X7 X10~X17、…、X370~X377。

· The EH2 series CPU can have up to 256 output points, numbered octal and ranging from Y0 to Y7 Y10~Y17、…、Y370~Y377。

· The usual operating voltage is DC24V.

· There are two types of output contacts: relays and transistors. When PPC907BE is used as a compact 4-axis controller, each axis is equipped with 4 digital inputs and 2

digital outputs, which can control four brushless DC or stepper motors. The rated power of each axis is up to 150 watts, and there are 3A peak current versions and 9A

peak current versions.

· When using PPC907BE as a compact 4-axis controller, each axis is equipped with one analog input.

· Common analog input signal ranges include 0-10V, 4-20mA, etc., but specific official data for this model's detailed range has not yet been found.

· Supports high-speed network communication, enabling remote programming, monitoring, and diagnostic functions.

· It has COM1 port (pluggable terminal block) and COM2 port (SUB-D plug), supporting multiple communication protocols such as Modbus, Profibus, CANopen, DeviceNet,

etc.

· It can connect different communication bus devices such as Profibus DP, CANopen, DeviceNet, and Modbus to form distributed I/O with the CPU, requiring an independent

FBP bus adapter.
