GFD563A102 3BHE046836R0102 ABB | excitation control system

GFD563A102 3BHE046836R0102 is an industrial control module produced by ABB, which has multi scenario application capabilities and high-performance features. The

specific description is as follows:

1. Core functions and classification

Core component of excitation control system: As a key module of the electric excitation system, it is used to regulate the magnetic field strength of the AC motor, achieve

precise control of motor speed and torque. Its advantage lies in its convenient and economical performance optimization, supporting energy-saving and emission reduction

goals

High speed digital output module: with fast response capability (as low as microsecond level delay), supporting multi-channel independent control (expandable to 1024 I/O),

suitable for real-time control requirements in industrial automation, such as production line equipment, robot motion control, etc

2. Technical characteristics

Reliability design: Adopting industrial grade anti-interference design, it can withstand harsh environments such as high temperature and vibration, with built-in overcurrent/short-circuit protection mechanism, and MTBF (mean time between failures) of over 100000 hours

Modular Expansion: Supports standardized communication protocols (such as EtherCAT), can be flexibly integrated into existing control systems, and provides multiple

configuration options (such as IO interfaces, control algorithms) to meet customized needs

3. Typical application scenarios

In the field of power and energy, it is widely used in the excitation system of power plants to achieve accurate monitoring of generator voltage/current and ensure stable

operation of the power grid

Intelligent Manufacturing and Transportation: Used for CNC machine tools, rail transit signal systems, and autonomous vehicles, providing high-precision control command

output

4. Physical parameters and maintenance

Structural specifications: Module size 380mm × 142mm × 73.5mm, weight 1.54kg, compact design for easy installation.

Maintenance support: Supports remote diagnosis and preventive maintenance plans, equipped with real-time monitoring function, with a fault response time of less than

50ms, effectively reducing downtime losses
